 AWM3069 Fiberglass Resin Silicone Rubber Wire

AWM3069 Fiberglass Resin Silicone Rubber Wire

Conductor: Bare, tinned copper
Insulator: Silicone rubber
Jacket: Silicone resin coating fiber glass braid
Color: Red, white, yellow, green, blue, black
Rated volt: 600V
Test voltage: 2500V. 15min
Rated temp: 150℃

Technical Parameters
AWG NO. Conductor Insulation Thickness Braid
mm
Wire OD Max. Resis.
Ω/KM
Size
mm²
Stranding
No./mm
OD
mm
Nominal
mm
OD
mm
Nominal
mm
OD
mm
26 0.128 7/0.16 0.48 0.76 2.00 0.25 2.50 ±0.20 148
24 0.205 7/0.20 0.60 0.76 2.15 0.25 2.65 ±0.20 93
11/0.16
22 0.324 7/0.25 0.75 0.76 2.30 0.25 2.80 ±0.20 55
13/0.18
20 0.519 7/0.31 0.96 0.76 2.50 0.25 3.00 ±0.20 34.6
10/0.254 40.1

Mechanical Properties
Tensile strength: ≥3.45N/mm²
Elongation at break of insulation: ≥120%
Min. bending radius: 6×OD

Characteristics
AWM3069 fiberglass resin silicone rubber wires have very good flexibility and good performance of resistance to high temperature, ranging from -55℃ up to 180℃.
The use of silicone rubber, a high grade corona resistant insulation material, gives the cable excellent dielectric strength.
The braided synthetic yarn covering, which is applied directly over the insulation, gives the cable, because of its short braiding pitch and high compactness, an excellent mechanical protection by maintaining good flexibility.
The varnishing of the braiding results in good antifriction properties, high abrasion resistance and excellent chemical resistance against transformer oil, light fuel oil and most types of cleaning agents.
In the event of fire, no corrosive and toxic gases will be given off.
Hence, damage caused by fire can be kept to minimum.

Application
AWM3069 fiberglass resin silicone rubber wire is used where high flexibility is required and in high temperature. It is therefore a suitable connection cable for home electric appliance, high voltage machines like transformers, generators, motors, traction machines.
