AWM 3135 Heat Resistant Silicone Rubber Wire

Conductor: Bare, tinned copper
Insulator: Silicone rubber
Rated volt.: 600V
Test voltage: 2000V. 1min
Rated temp.: -60℃～+200℃

Application
AWM 3135 heat resistant silicone rubber wires are used where high flexibility is required and in high temperature conditions. It is therefore a suitable connection cable for home electric appliance, high voltage machines like transformers, generators, motors, traction machines.

Technical Parameters

AWG No.	Conductor			Insulation	Wire OD		Resistance Ω/KM Max.
	Size	Structure	OD	Normal	Normal	Tolerance
	mm²	No./mm	mm	mm	mm	mm
26	0.128	7/0.16	0.48	0.76	2.00	±0.10	148
24	0.205	7/0.20	0.6	0.76	2.15	±0.10	93
22	0.324	7/0.25	0.75	0.76	2.3	±0.15	55
20	0.519	7/0.31 10/0.26	0.96	0.69	2.4	+0/-0.10	34.6
18	0.823	7/0.39 16/0.26	1.20	0.76	2.75	±0.20	21.8
16	1.31	7/0.49	1.47	0.76	3.00	±0.20	13.7
16	1.31	26/0.26	1.55	0.76	3.10	±0.20	13.7
14	2.08	7/0.62 41/0.254	1.90	0.76	3.45	±0.25	8.62
12	3.31	19/0.50 43/0.32	2.50	0.76	4.05	±0.25	5.38
26	0.128	1/0.42	0.42	0.76	1.95	±0.10	142
24	0.205	1/0.52	0.52	0.76	2.05	±0.10	89
22	0.324	1/0.65	0.65	0.76	2.20	±0.15	54.3
20	0.519	1/0.82	0.82	0.76	2.35	±0.15	33.9
18	0.823	1/1.05	1.05	0.76	2.60	±0.20	21.4
16	1.31	1/1.30	1.30	0.76	2.85	±0.20	13.5

Mechanical Properties
Tensile strength: 3.45N/mm2 min.
Elongation at break of insulation: ≥100%
Min. bending radius: 6×OD
Standard: UL758, UL62, And UL1581
Meet with RoHS, REACH rules.

Characteristics
AWM 3135 heat resistant silicone rubber wire has very good flexibility and good performance of resistance to high temperature, range from -55℃ up to 200℃.
The use of silicone rubber, a high grade corona resistant insulation material, gives the cable excellent dielectric strength.
